110683 - Design and Analysis of Shape Memory Spring Tires for Martian and Lunar Rover Vehicles

Shape memory alloys (SMAs) have played an important role in various innovative engineering and medical applications, such as aerospace actuators, vibration damping devices, and coronary stents. In applications, shape memory alloys are commonly utilized in two fundamentally different ways: (i) making use of the superelasticity/ pseudoelasticity (SE/PE) phenomena, as in applications in biomedical engineering, and (ii) taking advantages of the shape memory effect (SME), as is used for actuators. Their ability to act in such vastly different capacities is mainly due to their unique capability to recover large amounts of deformation produced by either applied stresses or temperature changes. One recent emerging application in use of SMAs has been in the area of non-pneumatic tire designs for Martian or Lunar roving vehicles. These vehicles require tires that are capable of traversing rugged terrain while withstanding extreme temperatures and atmospheric conditions. Inspired by the flexible wire mesh tires used on three Lunar Roving Vehicle (LRV) missions to the Moon on Apollo 15, 16, and 17, a new compliant tire technology was developed by the NASA Glenn Research Center (GRC) and Goodyear Tire & Rubber, known as the Spring Tire [1]. The Spring Tire consists of several hundred coiled springs woven into a flexible mesh and formed into the shape of a tire. Like the LRV wire mesh tires, the original Spring Tires were made from spring steel and were prone to permanent deformation when undergoing high localized loads.  Later, a new iteration of this technology was invented, known as the ‘Superelastic Tire’ [2]. This new technology incorporated the use of superelastic SMA springs, which could effectively undergo approximately 30 times more reversible deformation than the steel spring.  It also provided even greater durability and allowed for more flexibility in design, such as the use of other structural forms to reduce mass or increase load carrying capacity. Because of the unique nature of both the SMA material and the complex interactions between the springs, designing Spring Tires for a specific application requires extensive effort.  Historically, design decisions have relied on full-scale empirical testing; however, this is very expensive and time consuming, especially when multiple iterations are needed.  Therefore, developing a large-scale, robust, and predictive numerical model entailing complex spring interactions and the shape memory material behavior within a tire construct is the first essential step towards a successful design program. The current work focuses on implementation of the user-defined Shape Memory Alloy (SMA) model, otherwise known as SMA-GVIPs, in the Finite Element analysis (FEA) program ABAQUS for large-scale simulations of the GRC-developed Spring Tires made of SMA. The novelty of this work lies in the thorough, detail-oriented, and computationally efficient finite element analysis of full-scale SMA tires. A well-thought material characterization plan followed by model validation and a systemic sensitivity study on SMA tires has never been reported in the previous literature. The main objective of this study is to help the team improve and optimize the structural design of the SMA tires through in-depth numerical analysis and sensitivity studies. Various design variables (wire diameter, coil diameter, pitch, bead angle, and number of springs) were varied to study their influence on the global load-displacement response of the tire construct. A detailed investigation of the three-dimensional stress states was also carried out to enhance our understanding of the local changes as the tire goes through global deformation. It was concluded that a robust numerical model with a good predictive capability, together with a thoughtfully crafted sensitivity study can result in improved design iterations required to reach a desired tire performance while, significantly reducing manufacturing, labor and testing expenses. A summary of the Finite Element (FE) model construction will be presented together with a description of the user-defined SMA model, characterization process, experimental results, model validation, and numerical sensitivity study results.

1) Ansani et al. (2011). Spring Tire- NASA TM-20110002987.

2) Padula et al. (2019). Superelastic Tires-Patent number 10449804.
